CNC 6-Sided Drilling Machine with sawblade ND510S
From:
A versatile compact drilling machine with drilling units on top and bottom, designed to accommodate various batch sizes and patterns, offering maximum flexibility for complex production needs.
3D View - Drag to rotate
Key Features
- Easy application
- High quality
- Reduce material consumption
- Save on labor force
- 6-sided drilling
- Grooving saw top
- Routing
- 3 years of warranty
Description
This ND510S multi-functional CNC drilling machine is able to drill from 6 sides, top grooving and routing, simple routing meets different process requests and gives batch-size-one production max flexibility. Machine is configured with one top and one bottom drilling blocks.
Software is open port, support most formats in market. Standard with side outfeed conveyor table, selectable to outfeed from front and back.
The machine is in compliance with the applicable CE directives.
Table size | 1232x275x955mm |
Panel length | 200-3000 mm |
Panel width | 30-1000 mm |
Panel thickness | 10 – 60 mm |
Vertical drills | 10 |
Horizontal drills | X: 6 + Y: 4 |
Bottom drills | 9 |
Grooving saw | 1 x 1.7 kW – Φ100x22mm Z=14 |
Main spindle | ER25 x 1 |
3.5 kW 18000RPM | |
Feeding speed | 135/135/75/30 m/min |
Transmission mode: | X & Y axis Rack and pinion |
Transmission mode: | Z axis Ball screw |
Transmission mode: | Side alignment Rack and pinion |
Total power | 13.87 kW |
Weight | 3,850 kg |
Overall dimensions | 3962 x 2222 x 2271 |
Control system | SYNTEC |
