NCB-series
The series is developed for the wood and furniture industry, offering a precise and reliable solution for 6-sided drilling and milling in a single operation.
The machines are built with robust components, a vacuum table, and modern operation via a 15″ touchscreen. CNC control and open software make it easy to integrate the machines into existing production environments – whether for series production or special projects.
The two models have been carefully selected to cover different needs and production requirements:
NCB612DXT (Premium) – top model with double drilling heads, two main spindles, and maximum flexibility for high-volume production.
NCB612 (Standard model) – compact and versatile machine with one top drilling unit. Suitable for medium-sized productions requiring flexibility and precision.
Five Advantages of the NCB Series
- 6-sided processing – drilling, milling, and grooving in a single operation
- Powerful drilling heads and high-speed spindles (up to 5.5 kW)
- Vacuum table and automatic workpiece positioning
- 15″ touchscreen with SYNTEC control
- Ready for integration with CAD/CAM, nesting, and ERP systems
Exterior
- Stable steel construction with vibration damping
- Side outfeed conveyor as standard (front/rear outfeed optional)
- Compact machine layout with single-side access
- CE-certified and equipped with safety systems
Operation and Control
- User-friendly 15″ touchscreen
- SYNTEC-based control with upgrade options
- Automatic adjustment of drilling positions and milling depth
- On-screen error display and maintenance notifications
Updates and New Features
- Improved user interface and faster control response
- Prepared for label printer and full ERP integration
- Increased processing speed and precision
- Extended software compatibility and flexible data import
NCB612DXT CNC 6-Sided Drilling Machine
Premium
Selected standard equipment and features:
- 6-sided processing in a single operation
- Top and bottom drilling units with milling function
- Vertical drills: 16 × 2
- Horizontal drills: 4 × 2 (X) + 4 × 2 (Y)
- Bottom drills: 10 pcs
- Main spindles: 5.5 kW and 3.5 kW (18,000 RPM)
- Grooving and milling on both top and bottom sides
- SYNTEC control with 15″ color touchscreen
- Open software platform – supports most file formats
- Automatic measuring and positioning of workpieces
- Side outfeed conveyor (standard), front/rear outfeed available
- Vacuum table for precise workpiece clamping
- Feed speed: 135 / 135 / 75 / 30 m/min
- X and Y axes: rack and pinion
- Z axis: ball screw
- Side alignment: rack and pinion
- Working area: 1350 × 688 mm
- Panel dimensions: length 200–2400 mm, width 30–1200 mm, thickness 8–50 mm
- CE-certified and ready for Industry 4.0 integration
- Total power: 22.5 kW
- Machine weight: 3,850 kg
- External dimensions: 5700 × 2990 × 2200 mm
Pris fra:
Kontakt for tilbud
NCB612 CNC 6-Sided Drilling Machine
Standardmodel
Selected standard equipment and features:
- Machine length: 4050 mm
- Panel size (min.): 120 × 60 mm
- Panel thickness: 10 – 60 mm
- Edge band thickness: 0.4 – 3 mm
- Feed speed: 16 / 20 / 24 m/min
- Total power: 11.1 kW
- Weight: 1380 kg
- 7″ touchscreen with simple PLC control
- Automatic energy-saving standby mode
- Compact CNC-machined machine base for stability
- Glue pot with dosing system
- 2-motor cross-cutting unit
- 1 fine milling unit for edge processing
- Radius scraping unit
- Buffing/polishing unit
- Simple and fast work cycle: gluing, trimming, milling, scraping, and polishing
- Electronics from recognized manufacturers
- Individual frequency control per unit
- Coded cables and technical documentation
Pris fra:
Kontakt for tilbud
FAQ – NCB-series CNC 6-Sided Drilling
What is the difference between NCB612 and NCB612DXT?
NCB612:
– One top drilling unit
– 5.5 kW + 3.5 kW main spindle
– Vertical, horizontal, and bottom drilling
– Suitable for medium-sized production
NCB612DXT:
– Double drilling head for increased speed and capacity
– Same spindle power (5.5 kW + 3.5 kW), but with independent control
– Advanced routing and full 6-sided drilling in a single pass
– Suitable for high-volume and complex production
Which materials can the machines process?
The NCB series is designed for drilling and milling wood-based panels, such as:
- Particleboard
- MDF
- Veneered and laminated materials
- Plywood and lightweight composite panels
The machines can handle panel thicknesses ranging from 8–50 mm..
Is operation simple?
Yes. Both models are equipped with:
- 15″ color touchscreen
- SYNTEC control with intuitive interface
- Automatic workpiece measurement and drilling position adjustment
- Error messages and maintenance notifications
- Option for network connection and remote support
What equipment is included as standard?
Both NCB612 and NCB612DXT include:
- Vacuum table for precise clamping
- Upper and lower drilling unit
- Milling unit and grooving function
- Side outfeed conveyor
- Automatic lubrication system
Additionally, the NCB612DXT offers:
- Two top drilling units with independent control
- Increased flexibility for different workpiece sizes and cycles
Are there safety features?
Yes. The machines are CE-certified and equipped with:
- Light curtain and emergency stop
- Automatic calibration and adjustment
- Enclosed cabin with operator safety in focus
- Error and system monitoring via touchscreen
How is the machine operated in practice?
The operator controls the entire drilling and milling process via the touchscreen:
- Import the workpiece file or select a program manually
- Place the panel and start the automatic cycle
- Adjust drilling and milling parameters as needed
- Monitor status, errors, and operation in real time
Which companies are the target group?
The NCB series is aimed at:
- Industrial companies needing flexible and precise drilling across many variations
- Furniture manufacturers
- Joineries and kitchen producers
- Interior design companies
