ND712DTL
The ND712DTL is a fully automated CNC line for six-sided drilling and milling – optimized for industrial-scale production. With dual work zones, integrated robot loading, and a sensor-controlled outfeed, it delivers high throughput, flexible part handling, and rapid changeovers – all in one compact footprint.
Ideal for high-mix, high-speed environments where precision, automation, and reliability are essential.
Five advantages of the ND712DTL
- Six-sided drilling in a single cycle – no flipping required
- Robot loading system with camera and barcode identification
- Dual work zones – double capacity without expanding footprint
- Sensor-controlled sorting and panel grouping
- Modular platform ready for ERP integration and scaling
Construction and Design
- Heavy-duty CNC-machined steel frame for 24/7 production
- Compact layout with integrated conveyors and robot cell
- Efficient dust and chip extraction (top and bottom ports)
- Cleaning and sorting unit in outfeed for ready-to-stack panels
Operation and Control
- SYNTEC CNC control system with intuitive interface
- Rack & pinion drive (X/U/Y), ball screw (Z) for high-speed precision
- Barcode scanning for automatic program selection
- Supports continuous flow or single-operator mode
- Open software platform for modern production integration
News and Updates
- New dual-zone architecture for increased output
- Improved spindle configuration with ER25 tool holders
- Updated barcode & vision system for smarter job recognition
- Future-ready with scalable modular platform for line integration
ND712DTL – 6-Sided CNC Drilling Line
Selected Standard Equipment and Features:
- 6-sided drilling, grooving, and routing in one operation – supports batch-size-one and high-volume production
- Dual workstations – process two panels independently and simultaneously
- Robotic feeding system with camera and barcode scanner for automatic job identification
- Panel size capacity: Length 250–2800 mm, Width 250–650/1200 mm, Thickness 10–60 mm
- Max. feed speed: X/U axis 135 m/min, Y axis 75 m/min, Z axis 30 m/min
- Main spindles: 2 × 3.5 kW + 2 × 5.5 kW, max 18,000 RPM (ER25)
- Drilling units (top and bottom):
- Vertical drills: Top 19 × 4, Bottom 9 × 2
- Horizontal drills: Top X = 3 × 8, Y = 2 × 4
- Max drill diameter: Ø35 mm, spacing: 32 mm, rotation speed: 5,000 rpm
- Automatic loading via industrial robot arm
- Sensor-based outfeed with sorting function
- Transmission:
- X/Y axis: rack & pinion
- Z axis: ball screw
- Control system: SYNTEC CNC – user-friendly and supports multiple file formats
- 4 × Ø200 mm top dust extraction ports + 2 × Ø125 mm bottom ports (≥28 m/s flow)
- Barcode reader for job tracking and program selection
- Total installed power: 52.36 kW
- Machine dimensions: 7400 × 4620 × 2650 mm
- Power supply: 400V / 50Hz / 3-phase
- Air supply: 0.6–0.7 MPa
- Total weight: 7,850 kg
- CE-certified – includes full safety system with emergency stop, sensors, and protective enclosures
Price from: 342.000€
FAQ – ND712DTL, 6-Sided Drilling
What materials can the ND712DTL process?
The ND712DTL is designed for precise 6-sided drilling, grooving, and routing of wood-based panels such as MDF, particleboard, plywood, chipboard, laminated, or veneered boards.
Its ability to drill from both top and bottom and handle workpieces of varying shapes makes it ideal for complex and customized furniture components.
Is operation simple?
Yes. The ND712DTL uses a SYNTEC control system with a user-friendly interface that supports multiple file formats and barcode input. Operation is fully automated from loading to outfeed, and features include:
- Outfeed with sorting system and cleaning unit
- Robotic panel loading with vision and barcode recognition
- Dual workstations for continuous or independent processing
- Real-time status and error monitoring via touchscreen
- Automatic panel positioning and clamping
What equipment is included as standard?
The ND712DTL comes fully equipped for high-capacity 6-sided processing:
- 6-sided drilling: Top and bottom modules with multiple drilling heads
- 4 main routing spindles (2 × 3.5 kW and 2 × 5.5 kW, max 18,000 rpm)
- Vertical drills (top): 19 × 4 | Horizontal drills: X = 3 × 8, Y = 2 × 4
- Bottom vertical drills: 9 × 2
- Max drill diameter: Ø35 mm
- Robotic loader with automatic job selection via barcode
- SYNTEC CNC system supporting open file formats
- Rack & pinion transmission (X/Y), ball screw (Z)
- Max speed: 135 m/min (X), 75 m/min (Y), 30 m/min (Z)
- Intelligent outfeed with cleaning and sorting unit
- CE-certified enclosure and full safety system
- 4 top + 2 bottom dust extraction outlets (Ø200 / Ø125 mm)
Are there safety features?
Yes. The ND712DTL is CE-certified and built with multiple layers of safety protection:
- Fully enclosed frame with emergency stop at key access points
- Sensor-based monitoring of position, air pressure, and spindle errors
- Vision system for automatic detection and panel verification
- Integrated cleaning system to maintain clear work zones
- Heavy-duty steel structure reduces vibration for precise operation
How is the machine operated in practice?
Daily operation is streamlined and highly automated:
- The robot picks panels from pallet or stack and places them onto the infeed rollers.
- Barcode and camera system scan the panel and select the correct program.
- The machine automatically positions, clamps, and processes all six sides.
- Grooving, drilling, and routing are performed in a single cycle.
- Finished parts are sorted and cleaned before exiting the system.
- Despite its capacity, the system can be run by a single operator if needed.
What type of companies are the target group?
The ND712DTL is ideal for:
- Large-scale furniture producers
- Batch-size-one manufacturers
- Automation-focused interior design factories
- Companies that require flexibility, precision, and high capacity in one integrated solution
It’s a future-ready machine designed for scalable production environments.
