Industrial-series
Industrial-series from NichoMachines
The Industrial Series from NichoMachines consists of four carefully selected robot models: Basic, Advanced, and Speed. The series is developed for companies in production and logistics that want to streamline workflows with reliable, user-friendly, and scalable robotic solutions.
The robots cover everything from simple pick-and-place tasks to advanced palletizing and machine tending, with lifting capacities up to 70 kg and flexible setups for both small and large production environments. All models are delivered as complete solutions, ready for fast integration into your production.
The three models cover different needs:
Basic (Standard Model) – 4-axis solution with 60 kg lifting capacity, ideal for classic palletizing and simple automation without the need for programming.
Advanced (Premium) – High-capacity model with 6 axes and 70 kg lifting capacity. Suitable for heavy and advanced applications such as palletizing and machine tending.
Speed (Plus Model) – Ultra-fast and flexible 6-axis robot with automatic pallet change and integrated conveyors – for efficient production with minimal downtime.
Five Advantages of the Industrial Series
- Lifting capacity tailored to different tasks and loads
- User-friendly operation via touchscreen, no programming required
- Fast setup and integration – all models delivered ready for operation
- CE certification and built-in safety systems
- Scalable solution, suitable for both single stations and larger production lines
Exterior
- Stable design with compact footprint
- Floor and ceiling mounting (depending on model)
- Supplied with grippers, fencing, conveyors, and sensors
- Ready for connection to vacuum, network, and automation
Operation and Control
- User-friendly HMI panels with touch function
- Pre-programmed standard cycles for palletizing and handling
- Sensor-based vacuum monitoring
- Quick gripper change option (Advanced and Speed)
- Error monitoring and safety feedback
News and Updates
- Faster operation and lower downtime with pallet change and conveyors
- Quick setup and standard programs for palletizing and machine tending
- Improved HMI interface with real-time operation and maintenance display
- CE certification compliant with current EU directives
Industrial Robotic Solution Premium
Selected Standard Equipment and Features:
- 6-axis industrial robot with high flexibility and fast operation
- Lifting capacity: 70 kg
- Reach: 2100 mm
- Repeatability: ±0.05 mm
- Range of motion:
- Axis 1: ±180°
- Axis 2: -90° to +135°
- Axis 3: -185° to +80°
- Axis 4: ±200°
- Axis 5: ±130°
- Axis 6: ±360°
- Automatic pallet change reduces downtime
- Suction cup gripper with release plates and vacuum sensors
- Handles workpieces up to 800 × 1600 × 20 mm and 30 kg
- Intuitive HMI touchscreen for control and monitoring
- 2 x motorized conveyors, 2.5 m each
- 1 x motorized roller conveyor, 1.5 m
- Robust construction for demanding industrial environments
- Installation: Floor or ceiling mounting
- Protection class:
- Robot body: IP54
- Wrist: IP65
- CE certified and delivered ready for installation
- System weight: 522 kg
Price from:
Contact for quote
Industrial Robotic Solution
Plusmodel
Selected Standard Equipment and Features:
- 6-axis flexible industrial robot with free movement in all directions
- Lifting capacity: 70 kg
- Reach: 2100 mm
- Repeatability: ±0.05 mm
- Range of motion:
- Axis 1: ±180°
- Axis 2: -90° to +135°
- Axis 3: -185° to +80°
- Axis 4: ±200°
- Axis 5: ±130°
- Axis 6: ±360°
- Suction cup gripper with quick-change and dual option
- Handles workpieces up to 800 × 1600 × 20 mm and 30 kg
- Pre-programmed and ready for operation – no additional programming required
- Intuitive HMI touchscreen for control and monitoring
- Sensors for monitoring vacuum efficiency
- Supplied with two fixed palletizing stations
- Safety fence with doors and safety lock
- Installation: Floor or ceiling mounting
- Protection class:
- Robot body: IP54
- Wrist: IP65
- Robust base and CE certified for industrial operation
- System weight: 522 kg
Price from:
Contact for quote
Industrial Robotic Solution
Standard
Selected Standard Equipment and Features:
- 4-axis industrial robot for palletizing and material handling
- Lifting capacity: 60 kg
- Reach: 2000 mm
- Repeatability: ±0.03 mm
- Range of motion:
- Axis 1: ±180°
- Axis 2: -35° to +90°
- Axis 3: -10° to +110°
- Axis 4: ±360°
- Suction cup gripper with vacuum monitoring sensors
- Pre-programmed robot – ready for operation without manual coding
- Intuitive HMI panel for user-friendly operation
- Complete cable routing and hoses in energy chain
- Two fixed palletizing stations included
- Safety fence with doors and safety lock
- Floor-mounted installation
- Robust and vibration-damped steel construction
- Protection class: IP54
- CE certified and ready for industrial operation
- System weight: 500 kg
Price from:
Contact for quote
FAQ – Industrial-series
What is the difference between the three models?
The three models differ mainly in lifting capacity, flexibility, and automation level:
- Speed – 6-axis robot with the same specifications as Advanced, but with higher operational efficiency, automatic pallet change, and integrated conveyors.
- Advanced – 6-axis robot with 70 kg capacity and flexible movement in all directions. Suitable for machine tending, palletizing, and pick & place.
- Basic – 4-axis robot with 60 kg lifting capacity and 2 m reach. Suitable for classic palletizing and simple automation.
Are the robots easy to install and use?
Yes. All models are delivered pre-programmed and ready to use, controlled via an intuitive HMI touchscreen. No advanced programming is required – the operator can select tasks directly from simple menus.
Does installation require special equipment?
No. The system is delivered complete with:
Safety fencing and sensors
Everything is ready for quick setup directly on the production floor.
For the Speed model: Motorized conveyors and roller conveyor
Fixed base for floor mounting
Grippers (suction cups), energy chain, and cables
How is safety ensured?
The robots are CE certified and equipped with:
- Protection class IP54 (Wrist IP65 on Advanced and Speed)
- Emergency stop, fencing, and lockable doors
- Vacuum sensors for safe lifting function
- Error and system monitoring via HMI panel
Are there safety features?
Yes. The machines are CE approved and equipped with:
- Light curtain and emergency stop
- Automatic calibration and adjustment
- Enclosed cabin with operator safety in focus
- Error and system monitoring via touchscreen
How are the robots operated in practice?
Operation is handled directly from the supplied touch panel:
- Monitor operation, errors, and status in real time
- Select standard program (e.g., palletizing, machine tending)
- Set number of items, size, and placement
- Start program with one press
What types of companies are the target group?
The Industrial Series is aimed at:
- Companies seeking efficient automation with low investment
- Manufacturing companies with repetitive lifting and placing tasks
- Logistics centers and packaging lines
- Wood, plastics, and metal industries
